Plano Excavator Parts - Excavators are important machines that are used in a variety of industries. They are extremely efficient in moving and transporting heavy loads within minutes. This industrial equipment is used in many industries including road work, bridge building, landscaping, construction and architecture. While tracked models are sometimes known as trackhoes, excavators go by many names including mechanical shovels, diggers and 360-degree excavators. There are many applications for excavators and their attachments including forestry, snow removal with snowplow attachments and a snowblower, material handling, river dredging, construction, brush cutting with a hydraulic saw and mower attachments, digging trenches, holes and foundations, mulching for forestry, working alongside a pile driver for driving piles, grading and landscaping, regular and open-pit mining, demolition work with hydraulic claw attachments and a breaker, drilling footings and for rock blasting with an auger attachment or hydraulic drill. An excavator is a popular kind of heavy construction equipment made up of particular parts. The dipper, boom, cab and bucket are situated on top of a rotating platform called the house. The house is situated on top of an undercarriage that has tracks or wheels. Excavators have evolved from steam shovels of yesteryear. Today’s hydraulic excavating models use hydraulic fluid to complete all functions and movement. The linear actuation on the hydraulic cylinders makes them differ from cable-operated excavators that rely on winches or steel ropes. Excavator Models There are numerous sizes and models when it comes to hydraulic excavators. Tiny and compact models weigh approximately 2k lbs. while the largest models weigh in around 2m lbs. Modern hydraulic excavators rely on engine power to operate three hydraulic pumps as opposed to mechanical drivetrain operations. Two pumps deliver high-pressure oil for the accessories, swing motor, track motors and arms. A low-pressure third pump delivers power to pilot the spool valves. This setup enables less physical effort required for the operating controls. The three excavator pumps typically consist of a gear pump and two variable displacement piston pumps. These pumps are arranged in the excavator in a variety of formats depending on different manufacturer models. The House and the Undercarriage The house and the undercarriage make up the two main portions of the machine. The undercarriage is comprised of the tracks, track frame, the gears and the hydraulic motor that operates the blade tracks. The house features the engine, hydraulic oil tanks fuel, counterweight and the operator cab. A center pin connects the undercarriage to the house. A hydraulic swivel located at the pin axis supplies high-pressure oils to the hydraulic motors’ tracks. This design allows the excavator to move freely in 360 degrees. The house is available in a variety of configurations and is attached to the main boom. The most common type of booms are the mono booms. This kind of boom offers zero movement other than up and down motions A knuckle boom is another option which allows it to move right and left in line with the machine. Typically an option on compact excavators, the booms’ base has a hinge option that enables it to pivot one-hundred and eighty degrees independently to the house. Triple articulated booms are also on the market. At the end of the boom, the stick or dipper arm is located. This apparatus provides the required digging force to drag the bucket through the ground. The stick length is optional depending on if reach or breakout power is needed. Longer stick models are utilized for reach applications, while shorter sticks are used for breakout power situations. A bucket is typically attached to the end of the stick. A mud bucket describes a large, wide capacity bucket that has a straight cutting edge used for leveling and cleanup or wherever teeth are not needed. General purpose buckets are usually stronger and smaller with hardened teeth and side cutters to break up rocks and difficult ground. There are many different buckets of varying sizes for different applications. There are many attachments used for crushing, boring, cutting, lifting, ripping and more. Prior to the ‘90s, all excavating equipment came with a conventional counterweight that was suspended off of the back of the machine. This was in place to add more lifting capacity and digging force. As one can imagine, this became cumbersome when working within confined spaces. The counterweight of modern machines today is designed to stay in the width of the tracks making it much safer and more user-friendly within confined spaces. In excavators, there are two main kinds of control configuration to operate the bucket and the boom called the ISO and the SAE. This configuration disperses the top four digging controls between two separate y-x joysticks, providing the operator with simultaneous control over all four movements. Certain excavators have switches to allow the operator to decide on which configuration they want to use during operation. Hydraulic excavator jobs have surpassed bucket and excavation tasks. Many attachments including an auger, a grapple or a breaker have become common hydraulic powered attachments. There are models that offer a quick coupler feature to simplify attachment mounting and increase efficiency. Excavators often work beside loaders and bulldozers. Most of the compact-sized excavator models have wheels and a backfill or dozer blade. This horizontal blade attaches to the undercarriage. It is used for pushing and leveling material back into a hole. 8 Main Excavator Types There are eight main kinds of excavators including the dragline, long reach, crawler, bucket wheel, backhoe, steam shovel, skid steer and suction. Steam Shovel Steam shovels are one of the original types of excavators. They utilized steam energy back in the day, while current models rely on diesel or electric motors. Steam shovels are similar to backhoes with the bucket or shovel facing away from the machine instead of facing it. This enables the operator to shove dirt away from the machine instead of pulling earth towards it. Steam shovels are popular for digging around objects that might interfere with a regular backhoe. Backhoe Backhoes are one of the most popular kinds of excavators. This equipment consists of a wheeled track base and large bucket that extends from an arm or boom above the ground. The bucket faces the operator cab and enables the operator to scoop earth toward the equipment. There are many kinds of excavators and sizes including heavy-duty applications such as dredging water and bridge construction to compact residential models ideal for backyard landscaping. The smaller models enable operators to work in tiny spaces; however, this translates to approximately a 200-degree swiveling capacity for digging close to the machine. Dragline Excavator Dragline excavators are designed similarly to a backhoe and include numerous lines and cables to support the bucket pulling motion. The dragline design enables operators to obtain a longer reach while digging deeper compared to a traditional backhoe. The cable and booms let users work over wet or unstable ground and in difficult locations unattainable by regular models. Skid Steer Excavators Skid steers are designed with their booms and buckets facing away from the operator. This design allows attachments to reach over the cab as opposed to around it. This design makes skid steers useful for negotiating tight turns and narrow locations. These machines often complete residential jobs such a digging pools, site cleaning and working in limited surroundings while removing debris. Suction Excavator Resembling a modern dump truck, these special excavators enable operators to use a large hose and vacuum technology to suck rocks and earth out of the ground. The material is transferred back to the truck. The suction excavator ensures a safer environment for digging around equipment and underground pipes compared to typical backhoes. Crawler Excavators Crawlers run on two tracks and not wheels. They are popular in the mining and construction industries. Also called compact excavators, these machines rely on hydraulic power components to lift heavy soil and debris. The chain wheel configuration allows the machine to traverse down hills with less risk, making them an ideal candidate for hilly locations and tricky terrain. Crawlers are slower in comparison to other models but offer better stability, flexibility and balance. Long Reach Excavators The long reach excavator showcases lengthier boom and arm components. They are ideal for hard-to-reach areas. The extendable arm offers more than 100 feet of horizontal reach. These machines are often used for demolition in applications working over a body of water. Various attachments can be fixed to the arm to complete jobs such as cutting, crushing and shearing. Bucket Wheel Excavator These excavators function with a large front wheel with built-in buckets and shovels. As the wheel rotates, rocks and dirt are scooped up in the buckets. Materials are transferred onto a conveyor belt that makes up a portion of the machine. The belt transfers the material into a bin that may be separate from the model or a part of the machine.
